The PM5 fuel cell test station is designed for the development and research of PEM fuel cell stacks ranging from 0.25 to 5 kW. This station is capable of controlling the flow, pressure, temperature, and humidity of the anode, cathode, and cooling loops of a fuel cell stack. It simulates operational conditions and collects comprehensive data from the stack.
Anode/Cathode Flow Rate, Stoich, Temperature, Humidity and Pressure Control
Dry/Wet Gas Switching
Estop and Manual Nitrogen Purge
Rapid Heating and Humidification of The Stack
Polarization Curves and Other Functional Tests
Cell Voltage Monitoring
Intrinsic Safety & Alarming System
HMI with Data Acquisition & Analysis
24/7 Unattended Operation
0V Operation
Cell Reverse
EIS
HFR
Rapid Humid
Dynamic Pressure
Anode Deadend
Water Balance
| Min P/kW | Max P/kW | H2/NLPM | Air/NLPM | Inlet DP/°C | Gas Temp/°C | Coolant/LPM | Current/A | Cell# | Stack Temp/°C | Gas Pressure /kPag | Cell Hardware | Endplate Heating | 0V Operation | Cell Reverse | EIS | HFR | Rapid Humid | Dynamic Pressure | Active Cooling | Anode Deadend | Cold Start | Water Balance |
| 0.25 | 5 | 125 | 300 | 90 | 100 | 15 | 1000 | 20 | 90 | 300 | O | O | O | O | O | O | O | O |
